Wireless Uplight

Wireless Uplight

✅️60 W RGBW + Warm White COB LED with a 30,000-hour lifetime

✅️IP66-rated for outdoor use

✅️Up to 12 hours of battery runtime, depending on operating mode

✅️Wireless DMX control with optional IR remote control

✅️Interchangeable diffusers with 15°, 24°, 45° and 60° beam angles
Share to
Send Inquiry
Description
Technical Parameters

Description





Combining warm white illumination with versatile colour effects, this battery-powered outdoor LED fixture offers a distinctive lighting solution for events, architectural accents, and decorative installations. Its 60W COB LED integrates RGBW and warm white output, delivering a luminous flux of 2,100 lm for both atmospheric lighting and creative colour displays.



Designed for adaptable beam shaping, the fixture features a 24° beam angle, complemented by 45° medium and 60° wide filters, plus a special 15° beam option for more concentrated lighting effects. This flexibility makes it easy to tailor light distribution to different environments and design requirements.



With W-DMX™ wireless control, an OLED touchscreen, and multiple standalone programmes, including colour mixing, tunable white, and strobe effects, lighting adjustments are convenient and versatile. The IP66-rated metal housing provides protection against dust and water jets, supporting reliable use in outdoor settings.



Its rechargeable battery delivers approximately 4 hours at full brightness, 8 hours in colour-jumping mode, or up to 12 hours in gradual-change mode. With a 2.5-hour recharge time and a compact 3.5 kg design, this fixture combines flexible colour control, adjustable beam options, and convenient cordless operation.



Clarify the special 15° beam optionMention the 30,000-hour LED lifetime



Specifications



Photometric Values

Light Source

60W COB LED
LED Life Average 30000 hours
Beam angle 24°
Field Angle 38°
Illuminance 4060 lx @ 1 m
Luminous Flux 2,100 lm
Exchangeable Filters Medium: 45°; Wide: 60°
Special Beam 15°

Colors

LED Type RGBW + WARM WHITE
Colors Red, Green, Blue, White, Warm white
Colors mixing Yes
Color Macros Yes
Tunable White Yes
Color Temperature Filter 1: 3,200 K; Filter 2: 4,500 K; 2,200 K

Effects

Built-in Programs Auto Programs
Electronic Dimming Yes
Dimming Curve Selectable
Dimming Response Selectable
Dimming Delay DMX Delay
Strobe Yes
PWM Frequency 4,000 Hz

Control

Control Modes W-DMX™, IR remote control (optional),Standalone modes
DMX Channels 7 / 9 / 11CH
DMX Functions CCT, Color Change, Color Fade, Color Macro, Dimmer, Dimmer Curve, Dimmer Fine, Dimmer Response, DMX Delay, LED PWM Frequency, RGBWA + UV Fine, Strobe
Display OLED Touchscreen

Mains Operation

Voltage AC 100-240V, 50/60Hz
Power Consumption 90W
Power Connectors External Power Supply

Battery

Rechargeable Battery Yes
Battery Runtime Full Brightness: Approx. 4 hours; Color Jumping: Approx. 8 hours; Gradual Change: Approx. 12 hours
Recharge Time Approx. 2.5 hours

Environmental

Protection Rating IP66
Maximum Ambient Temperature 0-40°C
Relative Humidity Below 85%, non-condensing

Housing

Housing Material Metal
Colors Black/ White

Cooling

Cooling system Heat Pipe

Dimensions & Weight

Product Dimensions (L x W x H) 201 × 198 × 237 mm (without bracket)
Net Weight 3.5 kg

Other Properties

Accessories 1 × Mounting Bracket, 2 × Filters, 1 × IR Remote Control
