Wireless Dmx LED Par

Wireless Dmx LED Par

✅️4×15W RGBWA+UV LEDs with 1400 lm luminous flux


✅️IP66-rated for outdoor use


✅️Up to 14 hours of battery runtime, depending on operating mode


✅️Wireless DMX control with optional IR remote control


✅️Interchangeable diffusers with 22°, 32° and 45° beam angles
Share to
Send Inquiry
Description
Technical Parameters

Description





Designed for versatile outdoor lighting applications, this battery-powered LED fixture combines vibrant colour effects, flexible wireless control, and reliable weather protection in a compact design. Its RGBWA + UV colour spectrum delivers a wide range of creative lighting possibilities, making it ideal for events, architectural accents, and temporary outdoor installations.



Powered by 4 × 15W LEDs, the fixture offers a 22° beam angle and a 38° field angle for focused illumination. The included medium and wide filters provide additional flexibility, allowing users to adapt the beam spread to different lighting requirements. With W-DMX™ wireless control and an IR remote control, lighting effects can be adjusted conveniently without the need for a traditional wired DMX connection.



The IP66-rated housing provides protection against dust and water jets, making the fixture suitable for a variety of outdoor environments. Its rechargeable battery supports approximately 4 hours of operation at full brightness, up to 8 hours in colour-jumping mode, and up to 14 hours in gradual-change mode. With a 2.5-hour recharge time, a built-in OLED touchscreen, and a lightweight 3.5 kg construction, this fixture offers a practical and flexible solution for professional event lighting and creative outdoor applications.



Specifications



Photometric Values

Light Source

4 × 15W LEDs with 50,000hours life expectancy

Beam angle

22°

Field Angle

38°

Illuminance

6,750 lx @ 1 m

Luminous Flux

1,400 lm

Exchangeable Filters

Medium: 32°; Wide: 45°

Colors

LED Type RGBWA + UV 6-in-1
Colors Red, Green, Blue, White, Amber + UV
Colors mixing Yes
Color Macros Yes
Tunable White Yes
Color Temperature Control Filter 1: 3,200 K; Filter 2: 4,500 K; 2,200 K

Effects

Built-in Programs Auto Programs
Electronic Dimming Yes
Dimming Curve Selectable
Dimming Response Selectable
Dimming Delay DMX Delay
Strobe Yes
PWM Frequency 4,000 Hz

Control

Control Modes DMX512, W-DMXTM, Standalone, Infrared Remote Control (Optional)
DMX Channels 6 / 8 / 10CH
DMX Functions CCT, Color Change, Color Fade, Color Macro, Dimmer, Dimmer Curve, Dimmer Fine, Dimmer Response, DMX Delay, LED PWM Frequency, RGBWA + UV Fine, Strobe
Display OLED Touchscreen

Mains Operation

Voltage AC 100-240V, 50/60Hz
Power Consumption 75W
Power Connectors External Power Supply

Battery

Rechargeable Battery Yes
Battery Runtime Full Brightness: Approx. 4 hours; Color Jumping: Approx. 8 hours; Gradual Change:Approx. 14 hours
Recharge Time Approx. 2.5 hours

Environmental

Protection Rating IP66
Maximum Ambient Temperature 0-40°C
Relative Humidity Below 85%, non-condensing

Housing

Housing Material Metal
Colors Black/ White

Cooling

Cooling system Heat Pipe

Dimensions & Weight

Dimensions (W × D × H) 201 × 198 × 237 mm (without bracket)
Net Weight 3.5 kg

Other Properties

Accessories 1 × Mounting Bracket, 2 × Filters, 1 × IR Remote Control
