Stage 12x40w LED Moving head wash

Stage 12x40w LED Moving head wash

✅️12x40W Osram RGBW 4-in-1 LEDs deliver vibrant and uniform color mixing.

✅️Versatile 2.8° to 55° electronic zoom for flexible beam shaping.

✅️IP20-rated flame-retardant housing designed for reliable indoor applications.

✅️Adjustable 2500-8000K color temperature with 0-100% smooth dimming.

✅️540° pan and 270° tilt with precise 16-bit movement resolution.

✅️Color LCD display with DMX512, master-slave, and sound control modes.
Share to
Send Inquiry
Description
Technical Parameters

Description





Evolving the concept of the modern hybrid moving head, this 600W fixture integrates twelve 40W Osram RGBW 4-in-1 LEDs. Delivering a phenomenal 8,212 lumens at 10 meters in its narrowest 2.8° beam, it seamlessly transitions up to a massive 55° wash. The advanced optical system includes an adjustable 2500K-8000K color temperature (CCT) and smooth 0-100% dimming for absolute precision.



Unlocking high-resolution creative possibilities, it offers extensive channel configurations up to 68CH. Operators can execute dynamic 0-20Hz strobes and intricate color transitions via the full-color LCD display. Driven by 16-bit resolution, the 540° pan and 270° tilt movements are remarkably fluid. Furthermore, a low-noise fan cooling system with adjustable fan speeds ensures optimal thermal management across demanding indoor environments.



Encased in a high-temperature-resistant, flame-retardant engineering plastic chassis, this IP20-rated luminaire offers secure 3-pin/5-pin XLR and PowerCON connectivity. Weighing merely 14.3 kg, it delivers a highly versatile and dependable solution for touring productions, premium clubs, and live stage events.



Specifications



Photometric values

Light Source

12 × 40W Osram RGBW 4in1 LEDs

Beam angle

2.8° - 55° (Electronic Zoom)

Luminous flux

8212 lm

Illuminance

@ 10m (2.8°)

Colors

LED Type

40W 4in1 LED

Colors

Red, Green, Blue, White

Colors mixing

Yes

Color Temperature Presets

2500K - 8000K (Adjustable)

Effects

Electronic Dimming

0 - 100% smooth dimming

DMX Functions

Strobe (0-20Hz)

Control

Control Modes

DMX512, Master-Slave, Sound-Active

DMX Channels

18 / 24 / 68 CH

Display

Color LCD display

DMX Connectors

3-pin & 5-pin XLR

Mains operation

Voltage

AC100-240V, 50/60Hz

Power Consumption

600W

Power Connectors

powerCON In/Out

Environmental

Protection Rating

IP20

Indoor / Outdoor use

Indoor use

Operating Temperature

-20°C ~ 40°C

Housing

Housing Material

High temp resistant flame retardant engineering plastic

Colors

Black

Movement

Tilt

270°

Pan

540°

Movement Resolution

16-bit

Cooling

Cooling system

Low-noise fan cooling system with adjustable fan speed

Dimensions & Weight

Product Dimensions (LxWxH)

470 × 400 × 270 mm

Net Weight

14.3 kg
